The RedEye Intelligent Video Network Project

RedEye is an Intelligent Video Network that runs on a network of Linux computers with CSI and USB cameras. Computer Vision algorithms can be applied to any stream and changed on the fly. Interfaces with external systems like Robots and Video Storage services are available for custom applications. I wrote RedEye for my portfolio and because it very interesting.

RedEye is actually a collection of three independant applications, one could even say micro-services that act in concert to provide interesting applications built from streaming video sources, Computer Vision algorithms and Visualizations driven by a comprehensive API.

RedEye Components

RedEye is an OpenSource software project with a powerful API for integration with a variety of applications including but not limited to Robotics, Enviromental and Industrial Automation.

RedEye intends to be 100% API driven, infact supporting the following communication protocols: HTTP Server for REST and HTML, MQTT Client and Websockets for messaging and M-JPEG for video stream delivery.

  1. recam: streams video from networked camers (Raspberry Pi, Jetson Nano, Linux w/Webcam, etc.) through Computer Vision AlgoRithms and interfaces with Robotics!

  2. station: controls video streams, save videos, snapshots and change AI Algorigthms on cameras within it’s network.

  3. app: Webapp served by the station, a modern, nice looking app that can be used to watch video, observe algorights and even change them, on the fly.

  4. aeye: The A-Eye module (like the name? Pretty clever huh?) is a collection of Computer Vision filter plugins (easy to write, check out the examples) you can use OpenCV, NVidia Stuff or roll your own!

There links to each of these applications below where all the detail about how to get, build and run these applications can be found. Heck, in due time we may even get some containers built for easy deployment.

RedEye Architecture

RedEye can be called a Service Oriented Architecture made from the following Micro Services (Buzzword Kill). Bottom line is that each of the applications use standard open protocols making it very easy to integrate RedEye into many different applications and automations.

HTTP - WebUI, REST and File Uploads

The HTTP protocol is used quite a bit both for it’s REST interface as well as serving up HTML for the WebUI and providing file uploads. The recam and stations module provide HTTP servers.

MQTT - Messaging

RedEye depenends on an MQTT broker to facilatate camera discovery, event and error logging and camera controls. Both recam and stations are MQTT clients.

Websockets

RedEye comes with a WebUI (written in Vue)! Websockets provide realtime communication between the Stations service and the WebUI. Websockets allow humans to control much of the run time control of the network as well as observe it’s health.

M-JPEG - Video Streamer

M-JPEG is not the most efficient video streaming mechanism but it is relatively simple, used for a couple decades around the Internet and Computer Vision algorithms, which is what we’re all about!

All camera [recams] stream their video’s using M-JPEG accessible via a common URLs:

The above URLs are used to access the first and second video cameras on the device with the name: cam1 in mobilerobot.io.

Computer Vision Filters

Computer vision filters are very simple to integrate into RedEye: a shared library that exposes a single public function:

void* filter( void* img );

The filter can be included with RedEye and recompiled, or the filter can be built as a shared library and loaded at runtime.

Computer vision filters simply take an image in, do some possible transformations and return the transformed image. Entire pipelines can be built by stacking independent filters.

External Controls

RedEye easily interfaces with GPIO libraries like WiringPI that can be used to control electro-mechanical devices like industrial robots or agricultural controls.

It is also easy (for a competent programmer) to integrate a variety of external physical devices via Serial Port, i2c, SPI and good ol TCP sockets.

Open Source all on Github

RedEye is an Open Source project that organizes and controls a network of in-expensive Raspberry Pi and Jetson Nano Camera’s for example, though in theory any M-JPEG streamer would do!

Give it a Try, Let me know what you think!
